Nickel Alloy Cladding Waterwall Panel Boiler Inconel 625
| Place of Origin | CHINA |
|---|---|
| Certification | ISO, ASME, EN |
| Model Number | overlay waterwall panel |
| Minimum Order Quantity | 10 tons |
| Price | Negotiable |
| Packaging Details | Iron Frame |
| Delivery Time | 30 working days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 1000 tons / months |
Product Details
| Application | Industry,oil And Gas | Grade | Nickel Base Alloy,Inconel 625 |
|---|---|---|---|
| Type | Nickel Pipe,Nickel Tube/pipe | Shape | Inconel Tube / Pipe |
| Material | Inconel,Monel/Inconel/Incoloy/ Hastelloy/PH Stainless Steel,Inconel 600/UNS N06600 | Standard | Inconel600,EN,ASTM |
| High Light | ISO Cladding waterwall panel,ISO Nickel Alloy waterwall panel,ISO Inconel 625 water wall boiler |
||
Product Description
Nickel Alloy/Inconel 625 Cladding water wall panel/ Boiler,membrane,anticorrosion
Production Information
Nickel base weld overlays are commonly used in the Power Industry to extend the life of equipment subjected to aggressive corrosion enviroments.
As boiler conditions have become more aggressive over the years,Nickel base alloy overlays have become more commonly used,not just for repair and maintenance purposes,but also as a cost effective solution for new boiler installations.
|
Component |
Non-clad steel |
Steel clad with Alloy 625 |
|
Membrane wall in combustion room – lower area |
6-9 months |
3-4 years |
|
Membrane wall in combustion room – higher area |
2 years |
> 8 years |
|
Reheater |
3-4 years |
> 4 years |
|
Base material |
» Pipe walls and single tubes in P235GH, 15Mo3, 13CrMo44, 10CrMo910 |
|
Welding materials |
» Alloy 622 (US), alloy 625, alloy 686 (super heater tubes) galvanizing |
|
Shielding gas |
» 4-component shielding gas: He = 32 %, H2 = 2 %, CO2 = 0.05 %, remainder Ar » Alternative choices of shielding gas |
|
Welding equipment |
» GMAweldingequipmentwithpulsed-currentpowersources » Automatic burner processing |
|
Welding position |
» Vertical down position preferred, layer width 15 - 20 mm |
|
Option for application |
» On-site in the boiler with mobile welding equipment, minimum wall thickness 3 mm » Welding in the workshop weld metal overlay on new pipe walls and single tubes |
|
Technical requirements |
|
The most common problem in surfacing is cracking. The main methods to prevent cracking are as follows
1. Preheat before welding, control interlayer temperature and slow cooling after welding
2. Stress relief heat treatment after welding
3. Avoid multi-layer surfacing and use low hydrogen surfacing electrode
4. If necessary, build up the transition layer between the surfacing layer and the base metal (use the electrode with low carbon equivalent and high toughness)
Attention must be paid to butt welding:
1. According to the use requirements, reasonable selection of surfacing alloy
2. Reduce the dilution ratio of base metal as much as possible
3. Improve productivity
4. It is expected that the hardfacing metal and base metal have similar expansion coefficient and phase transformation temperature
Purpose of Inconel Cladding on surface :
1. Extend service life
2. Reduce costs
3. Reduce spare parts
4. Reduce maintenance
