CCO Welding 718 Inconel Cladding Pipe 6-114mm 0.25mm-3.0mm
| Place of Origin | China |
|---|---|
| Brand Name | Cheonny |
| Certification | ISO9001 ,ASME , EN, JIS, AiSi, GB, DIN, API |
| Model Number | overlay cladding |
| Minimum Order Quantity | 1 tons |
| Price | Negotiable |
| Packaging Details | Customized |
| Delivery Time | 30 days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 1000 Tons/Month |
Product Details
| Application | Construcion/Building /Industry | Thickness | 0.25mm-3.0mm Or Customized |
|---|---|---|---|
| Outer Diameter | 6mm-114mm Or Customized | Grade | Inconel 625 |
| Shape | Round.square.Rectangle | Surface Treatment | Black Painted Or As You Require |
| High Light | ISO9001 718 Inconel Cladding Pipe,ISO9001 Inconel Cladding Pipe 6mm,ISO9001 0.25mm overlay cladding |
||
Product Description
Inconel 718 CCO Welding Overlay Cladding Tube/Pipe OD 6-114 mm
Nickel chrome ferro alloy Inconel 625 plate and sheet price
Inconel 718 have good fatigue resistance, radiation resistance, oxidation resistance, corrosion resistance, and good processability, good welding performance. It can be able to manufacture all kinds of complex shape parts.In the aerospace, nuclear power, oil industry, and in the extrusion die, in the above temperature range obtained the extremely widespread application.
Inconel series: 600,601,617,625,690,718,825
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
Bar:10-50mm
Specification
Minimum mechanical properties in the room temperature:
| Density | Melting point | Tensile Strength | Yield Strength | Elongation A 5 % | Brinell |
| (g/cm3) | (℃) | σb/MPa | σb/MPa | hardness | |
| 8.4 | 1290-1350 | 760 | 345 | 30 | ≤220 |
Products Description
Nickel Bar Nickel Alloy 625 Round Bar Inconel 718 bar Nickel Rod
|
Product Name
|
Nickel Bar Nickel Alloy 625 Round Bar Inconel 718 bar Nickel Rod
|
|
Material
|
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
|
|
Shape
|
Round, Forging, Ring, Coil, Flange, Disc, Foil, Spherical, Ribbon, Square, Bar, Pipe, Sheet
|
|
Grade
|
Duplex: 2205(UNS S31803/S32205), 2507(UNS S32750), UNS S32760(Zeron 100), 2304, 904L
|
|
Others: 253Ma, 254SMo, 654SMo, F50(UNS S32100)F60,F61, F65, 1J22, N4, N6, etc.
|
|
|
Alloy : Alloy 20/28/31
|
|
|
Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;
|
|
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617, Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
|
|
|
Haynes: Haynes 230/556/188
|
|
|
Inconel Series:
|
|
|
Inconel 600/601/602CA/617/625/713/718/738/X-750, Carpenter 20
|
|
|
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669, Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816 |
|
|
Incoloy: Incoloy 800/800H/800HT/825/901/925/926/330
|
|
|
GH: GH2132, GH3030, GH3039, GH3128, GH4180, GH3044
|
|
|
Monel: Monel 400/K500/R405
|
|
|
Nitronic: Nitronic 40/50/60
|
|
|
Nimonic: Nimonic 75/80A/90/A263
|
|
|
Specification
|
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm; Length 2000-5000mm Pipe: φ6-273mm; δ1-30mm; Length 1000-8000mm Sheet: δ 0.8-36mm; Width 650-2000mm; Length 800-4500mm |
|
Product
Characteristics
|
1. According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys.
2. According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc. |
|
Standard
|
GB, AISI, ASTM, DIN, EN, SUS, UNS, etc.
|
|
Certification
|
ISO, SGS
|
|
Application
|
High temperature components, such as turbine blades, guide vanes, turbine disks, high pressure
compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines. |
|
Delivery
|
7-25 days
|
Chemical Compostion
|
Item
|
1J33
|
3J01
|
3J9
|
4J29
|
4J32
|
4J33
|
4J45
|
FeNi50
|
Invar36
|
|
C
|
≤0.05
|
≤0.05
|
0.22-0.26
|
≤0.03
|
≤0.05
|
≤0.03
|
≤0.05
|
≤0.05
|
≤0.1
|
|
Mn
|
≤0.05
|
≤1.00
|
1.80-2.20
|
≤0.5
|
0.2-0.6
|
≤0.5
|
≤0.8
|
≤0.8
|
≤0.5
|
|
Fe
|
Rest
|
||||||||
|
P
|
≤0.020
|
≤0.020
|
≤0.03
|
≤0.02
|
≤0.02
|
≤0.02
|
≤0.02
|
≤0.02
|
≤0.006
|
|
S
|
≤0.020
|
≤0.020
|
≤0.020
|
≤0.02
|
≤0.02
|
≤0.02
|
≤0.02
|
≤0.02
|
≤0.04
|
|
Si
|
0.30-0.6
|
≤0.80
|
1.30-1.70
|
≤0.3
|
≤0.2
|
≤0.3
|
≤0.3
|
≤0.3
|
≤0.35
|
|
Ni
|
32.8-33.8
|
34.5-36.5
|
9.0-10.5
|
28.5-29.5
|
31.5-33
|
28.5-29.5
|
44.5-45.5
|
49.5-50.5
|
35-38
|
|
Al
|
1.0-2.0
|
1.00-1.80
|
--
|
--
|
--
|
--
|
≤0.1
|
≤0.1
|
--
|
|
Co
|
--
|
--
|
--
|
16.8-17.8
|
3.2-4.2
|
16.8-17.8
|
--
|
--
|
--
|
|
Ti
|
--
|
2.70-3.20
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
|
Cu
|
--
|
--
|
--
|
--
|
≤0.2
|
0.4-0.8
|
≤0.2
|
--
|
--
|
|
Cr
|
--
|
11.5-13.0
|
19.0-20.5
|
≤0.2
|
--
|
≤0.2
|
--
|
--
|
--
|
|
Mo
|
--
|
--
|
1.60-1.85
|
≤0.2
|
--
|
≤0.2
|
--
|
--
|
--
|
