ASME Automatic Weld Overlay Pipe Inconel 625 Nickel Base Alloy
| Place of Origin | CHINA |
|---|---|
| Brand Name | Cheonny |
| Certification | ISO, ASME, EN |
| Model Number | Inconel cladding tube |
| Minimum Order Quantity | 1000 tons |
| Price | Negotiable |
| Packaging Details | Iron Frame |
| Delivery Time | 30 working days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 1000 tons / months |
Product Details
| Application | Industry,oil And Gas | Grade | Nickel Base Alloy,Inconel 625 |
|---|---|---|---|
| Type | Nickel Pipe,Nickel Tube/pipe | Shape | Inconel Tube / Pipe |
| Material | Inconel,Monel/Inconel/Incoloy/ Hastelloy/PH Stainless Steel,Inconel 600/UNS N06600 | Standard | Inconel600,EN,ASTM |
| High Light | Automatic Weld Overlay Pipe Cheonny,Weld Overlay Pipe Inconel 625 Cheonny,ASME weld overlay Cheonny |
||
Product Description
ASME Standard Automatic Weld Overlay Pipe /steel tube
The advantages of surfacing method compared with other surface treatment methods are as follows:
1) The combination of overlay and base metal is metallurgical combination, with high bonding strength and good impact resistance.
2) The composition and performance of the overlay metal are adjusted easily. The conventional formula of arc welding electrode or flux core electrode is very convenient. Various alloy systems can be designed to adapt to different working conditions.
3) The thickness of overlay is large, and the thickness of the overlay layer can be adjusted within 2-30mm, which is more suitable for severe wear condition.
4) It can save cost and economy. When the base of workpiece is made of common materials and the surface is overlaid with high alloy, it not only reduces the manufacturing cost but also saves a lot of precious metals. In the process of workpiece maintenance, the welding alloy is reasonably selected and the surface of damaged workpiece is repaired by overlay welding. It can greatly prolong the life of the workpiece, prolong the maintenance period and reduce the production.
5) Because the welding technology is to increase or restore the size of parts by welding, or to obtain alloy layer with special properties on the surface of parts, it is not difficult and operable for the personnel who can master the welding technology skillfully.
Production Information of Automatic Weld Overlay
With automated weld overlay services, we offer of a full range of corrosion, erosion, cladding solutions services to the oil and gas as well as the power and pulp and paper market.
Utilizing advanced automated welding equipment our teams can repair corroded or eroded areas by building back the worn area, restoring to an acceptable thickness and applying an upgraded metallurgy to reduce future issues.
Automated weld overlay can be used for towers, separators, coker drums, reactors, tanks, digesters, boilers, nozzles, heat exchangers and more.
Fast and cost-effective repair method.
-
Global network with experts for weld-overlay.
-
High quality guaranteed thanks to welding certification.
Physical Properties:
| Density | 8.4g/cm³ |
| Melting Point | 1290℃-1350℃ |
Execution standard:
| Product | ASTM |
| Bar & Profile | ASTM B446 |
| Thick Plate,Sheet & Strip | ASTM B443 |
| Seamless pipe | ASTM B444 |
| Welded nominal pipe | ASTM B704 |
| Seamless & Welded pipe fittings | ASTM B704 |
| Forgings | ASTM B564 |
Minimum value of mechanical properties of alloys at the normal temperature:
| Alloy States | Tensile Strength | Yield Strength | Elongation | Hardness |
| RM N/mm² | RP0.2N/mm² | A5 % | HB | |
| Sheet & Strip | ≥827 | ≥414 | ≥30 | ≤220 |
| Plate | ≥827 | ≥414 | ≥30 | ≤220 |
| Bar | ≥827 | ≥414 | ≥30 | ≤220 |
Purpose of surfacing welding of Automatic Weld Overlay
1. Reduce costs
2. Extend service life
3. Reduce maintenance
4. Reduce spare parts
Our Service
High-quality products supplier
Customized products
Flexible requirements for order size
Diverse products
Competitive price
Professional technical and quality team
Professional sales team
RFQ
Q: Are you trading company or manufacturer ?
A: We are manufacturer
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 25-35days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample extra
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
